人脸识别5-Linux下交叉编译SeetaFace6

0、环境说明1、下载SeetaFace62、Linux下交叉编译2.0 编译顺序说明2.1 交叉编译OpenRoleZoo2.1.1 pot.h代码补丁2.1.2 编译过程
2.2 交叉编译SeetaAuthorize2.3 交叉编译TenniS2.4 交叉编译FaceAntiSpoofingX62.5 交叉编译FaceBoxes2.6 交叉编译FaceRecognizer62.7交叉编译FaceTracker62.8 交叉编译Landmarker2.9 交叉编译PoseEstimator62.10 交叉编译QualityAssessor32.10.1 LOCAL_ENV.cmake补丁2.10.2 编译过程
2.11 交叉编译SeetaAgePredictor2.12 交叉编译SeetaEyeStateDetector2.13 交叉编译SeetaGenderPredictor2.14 交叉编译SeetaMaskDetector
3 在Qt项目中使用opencv和SeetaFace6

0、环境说明

环境项	版本
操作系统	Ubuntu22.04
交叉编译工具链	/home/wongoing/Linux/itop/rk3588-linux/buildroot/output/rockchip_rk3588/host
交叉编译器gcc	${交叉编译工具链路径}/bin/aarch64-buildroot-linux-gnu-gcc
交叉编译器g++	${交叉编译工具链路径}/bin/aarch64-buildroot-linux-gnu-g++
cmake	3.22.1

1、下载SeetaFace6

SeetaFace6官网：

https://github.com/SeetaFace6Openhttps://github.com/SeetaFace6Open/index

把下载的index-master.zip解压到~/Linux/qt_workspace/thirdpart/SeetaFace/SeetaFace6目录下，这个目录可以根据自己的实际设定。

下载 https://github.com/SeetaFace6Open 下的各模块源码，解压至~/Linux/qt_workspace/thirdpart/SeetaFace/SeetaFace6/index-master目录下，覆盖各模块文件夹。

2、Linux下交叉编译

2.0 编译顺序说明

OpenRoleZoo 为常用操作的集合SeetaAuthorize 为模型解析工程TenniS 为前向计算框架。需要重点说明的是，此次 TenniS 同时放出了 GPU 计算源码，可以编译出 GPU 版本进行使用。

上述三个模块为基础模块，各个 SDK 的编译均依赖上述模块，因此需要优先编译出 OpenRoleZoo, SeetaAuthorize 和 TenniS，然后再进行其他 SDK 模块的编译。具体需进入每个目录的craft下选择对应的脚本进行执行。

2.1 交叉编译OpenRoleZoo

2.1.1 pot.h代码补丁

解决以下问题

error C2039: “function”: 不是 “std” 的成员error C2061: 语法错误: 标识符“function”error C4430: 缺少类型说明符 – 假定为 interror C2143: 语法错误: 缺少“,”(在“&”的前面)error C3646: “m_allocator”: 未知重写说明符error C4430: 缺少类型说明符 – 假定为 interror C2665: “orz::Pot::Pot”: 没有重载函数可以转换所有参数类型

修改SeetaFace6index-masterOpenRoleZooincludeorzmempot.h,增加以下代码：


#include <functional>  // 必须添加，用于 std::function

增加后的完整代码


//
// Created by Lby on 2017/8/12.
//

#ifndef ORZ_MEM_POT_H
#define ORZ_MEM_POT_H

#include <functional>  // 必须添加，用于 std::function
#include <mutex>
#include <memory>

namespace orz {

    class Pot {
    public:
        using allocator = std::function<std::shared_ptr<void>(size_t)>;

        Pot();
        Pot(const allocator &ator);

        void *malloc(size_t _size);

        void *relloc(size_t _size);

        template<typename T>
        T *calloc(size_t _count, bool copy = false) {
            if (copy)
                return reinterpret_cast<T *>(this->relloc(sizeof(T) * _count));
            else
                return reinterpret_cast<T *>(this->malloc(sizeof(T) * _count));
        }

        void *data() const;

        size_t capacity() const;

        size_t size() const;

        void dispose();

    private:
        allocator m_allocator;

    private:
        size_t m_capacity;
        size_t m_size;
        std::shared_ptr<void> m_data;
    };
}

#endif //ORZ_MEM_POT_H

2.1.2 编译过程

进入到~/Linux/qt_workspace/thirdpart/SeetaFace/SeetaFace6/index-master/OpenRoleZoo/craft目录下，复制脚本文件build.linux.x64.sh，命名为build.linux.rk3588.sh，内容如下：


#!/usr/bin/env bash
set -e

#TOOL_CHAIN=/home/wongoing/Linux/wg_rk3588_linux_sdk_v1.3.0/buildroot/output/rockchip_rk3588/host
TOOL_CHAIN=/home/wongoing/Linux/itop/rk3588-linux/buildroot/output/rockchip_rk3588/host
GCC_COMPILER=$TOOL_CHAIN/bin/aarch64-buildroot-linux-gnu

export LD_LIBRARY_PATH=${TOOL_CHAIN}/lib64:$LD_LIBRARY_PATH
export CC=${GCC_COMPILER}-gcc
export CXX=${GCC_COMPILER}-g++

export BUILD_DIR=build.linux.rk3588
export BUILD_TYPE=Release
export PLATFORM_TARGET=aarch64

export WITH_SSL=OFF

export INSTALL_DIR=$(cd "$(dirname "$0")"; pwd)/../../build

HOME=$(cd `dirname $0`; pwd)

echo $HOME

cd $HOME

mkdir -p "$BUILD_DIR"

cd "$BUILD_DIR"

cmake "$HOME/.."
-DCMAKE_BUILD_TYPE="$BUILD_TYPE"
-DPLATFORM="$PLATFORM_TARGET"
-DORZ_WITH_OPENSSL="$WITH_SSL"
-DCMAKE_INSTALL_PREFIX="$INSTALL_DIR"

make -j4
make install

cd -

注意：
以下为开头增加的内容：


set -e
#TOOL_CHAIN=/home/wongoing/Linux/wg_rk3588_linux_sdk_v1.3.0/buildroot/output/rockchip_rk3588/host
TOOL_CHAIN=/home/wongoing/Linux/itop/rk3588-linux/buildroot/output/rockchip_rk3588/host
GCC_COMPILER=$TOOL_CHAIN/bin/aarch64-buildroot-linux-gnu

export LD_LIBRARY_PATH=${TOOL_CHAIN}/lib64:$LD_LIBRARY_PATH
export CC=${GCC_COMPILER}-gcc
export CXX=${GCC_COMPILER}-g++

注意：
以下为修改的内容：


export BUILD_DIR=build.linux.x64
改为了
export BUILD_DIR=build.linux.rk3588


export PLATFORM_TARGET=x64
改为了
export PLATFORM_TARGET=aarch64


mkdir "$BUILD_DIR"
改为了
mkdir -p "$BUILD_DIR"


make -j16
改为了
make -j4

注意：
末尾增加的内容：


cd -

然后执行build.linux.rk3588.sh

2.2 交叉编译SeetaAuthorize

进入到~/Linux/qt_workspace/thirdpart/SeetaFace/SeetaFace6/index-master/SeetaAuthorize/craft目录下，复制脚本文件build.linux.x64.sh，命名为build.linux.rk3588.sh，内容如下：


#!/usr/bin/env bash
set -e
#TOOL_CHAIN=/home/wongoing/Linux/wg_rk3588_linux_sdk_v1.3.0/buildroot/output/rockchip_rk3588/host
TOOL_CHAIN=/home/wongoing/Linux/itop/rk3588-linux/buildroot/output/rockchip_rk3588/host
GCC_COMPILER=$TOOL_CHAIN/bin/aarch64-buildroot-linux-gnu

export LD_LIBRARY_PATH=${TOOL_CHAIN}/lib64:$LD_LIBRARY_PATH
export CC=${GCC_COMPILER}-gcc
export CXX=${GCC_COMPILER}-g++

export BUILD_DIR=build.linux.rk3588
export BUILD_TYPE=Release
export PLATFORM_TARGET=aarch64

export ORZ_HOME=$(cd "$(dirname "$0")"; pwd)/../../build
export INSTALL_DIR=$(cd "$(dirname "$0")"; pwd)/../../build

HOME=$(cd `dirname $0`; pwd)

cd $HOME

mkdir -p "$BUILD_DIR"

cd "$BUILD_DIR"

mkdir -p "$INSTALL_DIR"

cmake "$HOME/.."
-DCMAKE_BUILD_TYPE="$BUILD_TYPE"
-DPLATFORM="$PLATFORM_TARGET"
-DORZ_ROOT_DIR="$ORZ_HOME"
-DCMAKE_INSTALL_PREFIX="$INSTALL_DIR"

make -j4
make install

cd -

重点注意


mkdir "$INSTALL_DIR"
则改为
mkdir -p "$INSTALL_DIR"

2.3 交叉编译TenniS

进入到~/Linux/qt_workspace/thirdpart/SeetaFace/SeetaFace6/index-master/TenniS/craft目录下，复制脚本文件build.linux.x64.sh，命名为build.linux.rk3588.sh，内容如下：


#!/usr/bin/env bash
set -e
#TOOL_CHAIN=/home/wongoing/Linux/wg_rk3588_linux_sdk_v1.3.0/buildroot/output/rockchip_rk3588/host
TOOL_CHAIN=/home/wongoing/Linux/itop/rk3588-linux/buildroot/output/rockchip_rk3588/host
GCC_COMPILER=$TOOL_CHAIN/bin/aarch64-buildroot-linux-gnu

export LD_LIBRARY_PATH=${TOOL_CHAIN}/lib64:$LD_LIBRARY_PATH
export CC=${GCC_COMPILER}-gcc
export CXX=${GCC_COMPILER}-g++


export BUILD_DIR=build.linux.rk3588
export BUILD_TYPE=Release
export PLATFORM_TARGET=aarch64

export PLATFORM=x64
export INSTALL_DIR=$(cd "$(dirname "$0")"; pwd)/../../build

HOME=$(cd `dirname $0`; pwd)

cd $HOME

mkdir -p "$BUILD_DIR"

cd "$BUILD_DIR"


cmake "$HOME/.."
-DCMAKE_SYSTEM_NAME=Linux
-DCMAKE_BUILD_TYPE="$BUILD_TYPE"
-DCONFIGURATION="$BUILD_TYPE"
-DPLATFORM="$PLATFORM_TARGET"
-DCMAKE_INSTALL_PREFIX="$INSTALL_DIR"
-DTS_USE_OPENMP=OFF
-DTS_USE_SIMD=ON
-DTS_USE_NEON=ON
#-DTS_ON_HASWELL=OFF
#-DTS_DYNAMIC_INSTRUCTION=ON

make -j4

make install

cd -

重点注意：


-DTS_USE_OPENMP=ON
改为了
-DTS_USE_OPENMP=OFF


#-DTS_ON_HASWELL=OFF
#-DTS_DYNAMIC_INSTRUCTION=ON
替换为了
-DTS_USE_NEON=ON

2.4 交叉编译FaceAntiSpoofingX6

进入到~/Linux/qt_workspace/thirdpart/SeetaFace/SeetaFace6/index-master/FaceAntiSpoofingX6/craft目录下，复制脚本文件build.linux.x64.sh，命名为build.linux.rk3588.sh，内容如下：


#!/usr/bin/env bash
set -e
#TOOL_CHAIN=/home/wongoing/Linux/wg_rk3588_linux_sdk_v1.3.0/buildroot/output/rockchip_rk3588/host
TOOL_CHAIN=/home/wongoing/Linux/itop/rk3588-linux/buildroot/output/rockchip_rk3588/host
GCC_COMPILER=$TOOL_CHAIN/bin/aarch64-buildroot-linux-gnu

export LD_LIBRARY_PATH=${TOOL_CHAIN}/lib64:$LD_LIBRARY_PATH
export CC=${GCC_COMPILER}-gcc
export CXX=${GCC_COMPILER}-g++

export BUILD_DIR=build.linux.rk3588
export BUILD_TYPE=Release
export PLATFORM_TARGET=aarch64

export PLATFORM=aarch64
export ORZ_HOME=$(cd "$(dirname "$0")"; pwd)/../../build
export INSTALL_DIR=$(cd "$(dirname "$0")"; pwd)/../../build

HOME=$(cd `dirname $0`; pwd)

cd $HOME

mkdir -p "$BUILD_DIR"

cd "$BUILD_DIR"


cmake "$HOME/.."
-DCMAKE_BUILD_TYPE="$BUILD_TYPE"
-DCONFIGURATION="$BUILD_TYPE"
-DPLATFORM="$PLATFORM_TARGET"
-DORZ_ROOT_DIR="$ORZ_HOME"
-DCMAKE_INSTALL_PREFIX="$INSTALL_DIR"
-DCMAKE_MODULE_PATH=""
-DSEETA_AUTHORIZE=OFF
-DSEETA_MODEL_ENCRYPT=ON

make -j4

make install

cd -

2.5 交叉编译FaceBoxes

进入到~/Linux/qt_workspace/thirdpart/SeetaFace/SeetaFace6/index-master/FaceBoxes/craft目录下，复制脚本文件build.linux.x64.sh，命名为build.linux.rk3588.sh，内容如下：


#!/usr/bin/env bash
set -e
#TOOL_CHAIN=/home/wongoing/Linux/wg_rk3588_linux_sdk_v1.3.0/buildroot/output/rockchip_rk3588/host
TOOL_CHAIN=/home/wongoing/Linux/itop/rk3588-linux/buildroot/output/rockchip_rk3588/host
GCC_COMPILER=$TOOL_CHAIN/bin/aarch64-buildroot-linux-gnu

export LD_LIBRARY_PATH=${TOOL_CHAIN}/lib64:$LD_LIBRARY_PATH
export CC=${GCC_COMPILER}-gcc
export CXX=${GCC_COMPILER}-g++

export BUILD_DIR=build.linux.rk3588
export BUILD_TYPE=Release
export PLATFORM_TARGET=aarch64

export PLATFORM=aarch64
export ORZ_HOME=$(cd "$(dirname "$0")"; pwd)/../../build
export INSTALL_DIR=$(cd "$(dirname "$0")"; pwd)/../../build

HOME=$(cd `dirname $0`; pwd)

cd $HOME

mkdir -p "$BUILD_DIR"

cd "$BUILD_DIR"


cmake "$HOME/.."
-DCMAKE_BUILD_TYPE="$BUILD_TYPE"
-DCONFIGURATION="$BUILD_TYPE"
-DPLATFORM="$PLATFORM_TARGET"
-DORZ_ROOT_DIR="$ORZ_HOME"
-DCMAKE_INSTALL_PREFIX="$INSTALL_DIR"
-DCMAKE_MODULE_PATH=""
-DSEETA_AUTHORIZE=OFF
-DSEETA_MODEL_ENCRYPT=ON

make -j4

make install

cd -

2.6 交叉编译FaceRecognizer6

与FaceAntiSpoofingX6类似

2.7交叉编译FaceTracker6

与FaceAntiSpoofingX6类似

2.8 交叉编译Landmarker

与FaceAntiSpoofingX6类似

2.9 交叉编译PoseEstimator6

与FaceAntiSpoofingX6类似

2.10 交叉编译QualityAssessor3

2.10.1 LOCAL_ENV.cmake补丁

在在QualityAssessor3/cmake/LOCAL_ENV.cmake文件中，添加else判断（这个判断在其他模块是有的）代码如下：


	else()
		set(ENV_RUNTIME_DIR ${ENV_RUNTIME_DIR}/${PLATFORM})
		set(ENV_LIBRARY_DIR ${ENV_LIBRARY_DIR}/${PLATFORM})
		set(ENV_ARCHIVE_DIR ${ENV_ARCHIVE_DIR}/${PLATFORM})
	endif()

完整QualityAssessor3/cmake/LOCAL_ENV.cmake代码如下：


# set flags

set(ENV_RUNTIME_DIR "bin")
set(ENV_LIBRARY_DIR "lib")
set(ENV_ARCHIVE_DIR "lib")
set(ENV_HEADER_DIR "include")
set(ENV_SUFFIX "")

if (MSVC)
        if ("${PLATFORM}" STREQUAL "")
        elseif("${PLATFORM}" STREQUAL "auto")
        else ()
                set(ENV_RUNTIME_DIR ${ENV_RUNTIME_DIR}/${PLATFORM})
                set(ENV_LIBRARY_DIR ${ENV_LIBRARY_DIR}/${PLATFORM})
                set(ENV_ARCHIVE_DIR ${ENV_ARCHIVE_DIR}/${PLATFORM})
        endif ()
elseif (MINGW)
        if ("${PLATFORM}" STREQUAL "")
        elseif("${PLATFORM}" STREQUAL "auto")
        else ()
                set(ENV_RUNTIME_DIR ${ENV_RUNTIME_DIR}/${PLATFORM})
                set(ENV_LIBRARY_DIR ${ENV_LIBRARY_DIR}/${PLATFORM})
                set(ENV_ARCHIVE_DIR ${ENV_ARCHIVE_DIR}/${PLATFORM})
        endif ()
else()
        if ("${PLATFORM}" STREQUAL "x86")
                set(ENV_RUNTIME_DIR ${ENV_RUNTIME_DIR})
                set(ENV_LIBRARY_DIR ${ENV_LIBRARY_DIR}32)
                set(ENV_ARCHIVE_DIR ${ENV_ARCHIVE_DIR}32)
        elseif ("${PLATFORM}" STREQUAL "x64")
                set(ENV_RUNTIME_DIR ${ENV_RUNTIME_DIR})
                set(ENV_LIBRARY_DIR ${ENV_LIBRARY_DIR}64)
                set(ENV_ARCHIVE_DIR ${ENV_ARCHIVE_DIR}64)
        else()
                set(ENV_RUNTIME_DIR ${ENV_RUNTIME_DIR}/${PLATFORM})
                set(ENV_LIBRARY_DIR ${ENV_LIBRARY_DIR}/${PLATFORM})
                set(ENV_ARCHIVE_DIR ${ENV_ARCHIVE_DIR}/${PLATFORM})
        endif()
endif()

if ("${CONFIGURATION}" STREQUAL "Debug")
        set(ENV_SUFFIX "d")
endif ()

set(ENV_INCLUDE_DIR ${ENV_HEADER_DIR})

2.10.2 编译过程

与FaceAntiSpoofingX6类似

2.11 交叉编译SeetaAgePredictor

与FaceAntiSpoofingX6类似

2.12 交叉编译SeetaEyeStateDetector

与FaceAntiSpoofingX6类似

2.13 交叉编译SeetaGenderPredictor

与FaceAntiSpoofingX6类似

2.14 交叉编译SeetaMaskDetector

与FaceAntiSpoofingX6类似

3 在Qt项目中使用opencv和SeetaFace6


#windows adm64:
msvc {
    #添加头文件
    INCLUDEPATH += D:QtDepLibraryopencvopencv-4.5.5uildinstallinclude
    INCLUDEPATH += D:QtDepLibraryopencvopencv-4.5.5uildinstallincludeopencv2

    INCLUDEPATH += D:QtDepLibrarySeetaFaceSeetaFace6index-masteruildinclude
    INCLUDEPATH += D:QtDepLibrarySeetaFaceSeetaFace6index-masteruildincludeseeta

    #添加库
    win32:CONFIG(debug, debug|release) {
        LIBS += -LD:QtDepLibraryopencvopencv-4.5.5uildinstalllib -lopencv_world455d
        LIBS += -LD:QtDepLibrarySeetaFaceSeetaFace6index-masteruildlibx64
        LIBS += -lSeetaFaceDetector600d
        LIBS += -lSeetaFaceLandmarker600d
        LIBS += -lSeetaFaceAntiSpoofingX600d
        LIBS += -lSeetaFaceTracking600d
        LIBS += -lSeetaFaceRecognizer610d
        LIBS += -lSeetaQualityAssessor300d
        LIBS += -lSeetaPoseEstimation600d
    } else {
        LIBS += -LD:QtDepLibraryopencvopencv-4.5.5uildinstalllib -lopencv_world455
        LIBS += -LD:QtDepLibrarySeetaFaceSeetaFace6index-masteruildlibx64
        LIBS += -lSeetaFaceDetector600
        LIBS += -lSeetaFaceLandmarker600
        LIBS += -lSeetaFaceAntiSpoofingX600
        LIBS += -lSeetaFaceTracking600
        LIBS += -lSeetaFaceRecognizer610
        LIBS += -lSeetaQualityAssessor300
        LIBS += -lSeetaPoseEstimation600
    }
}
#Linux aarch64
!msvc {
    #添加头文件
    # opencv引用buildroot构建时的4.5.4
    INCLUDEPATH += /home/wongoing/Linux/itop/rk3588-linux/buildroot/output/rockchip_rk3588/host/aarch64-buildroot-linux-gnu/sysroot/usr/include/opencv4
    INCLUDEPATH += /home/wongoing/Linux/itop/rk3588-linux/buildroot/output/rockchip_rk3588/host/aarch64-buildroot-linux-gnu/sysroot/usr/include/opencv4/opencv2

    # SeetaFace6引用自己源码编译的
    INCLUDEPATH += $$PWD/../thirdpart/SeetaFace/SeetaFace6/index-master/build/include
    INCLUDEPATH += $$PWD/../thirdpart/SeetaFace/SeetaFace6/index-master/build/include/seeta

    #添加库opencv
    LIBS += -L/home/wongoing/Linux/itop/rk3588-linux/buildroot/output/rockchip_rk3588/host/aarch64-buildroot-linux-gnu/sysroot/usr/lib
    LIBS += -lopencv_core
    LIBS += -lopencv_imgproc
    LIBS += -lopencv_imgcodecs
    LIBS += -lopencv_videoio
    LIBS += -lopencv_highgui

    #添加库SeetaFace6
    LIBS += -L$$PWD/../thirdpart/SeetaFace/SeetaFace6/index-master/build/lib/aarch64
    LIBS += -lSeetaFaceDetector600
    LIBS += -lSeetaFaceLandmarker600
    LIBS += -lSeetaFaceAntiSpoofingX600
    LIBS += -lSeetaFaceTracking600
    LIBS += -lSeetaFaceRecognizer610
    LIBS += -lSeetaQualityAssessor300
    LIBS += -lSeetaPoseEstimation600
    LIBS += -lSeetaAuthorize
    LIBS += -ltennis
}
